15. ARI760F
電子型錄下載
ARI760F.pdf| Rated load | 2、5、10、20、50、100 kg |
|---|---|
| Comprehensive error | ≤±1% |
| Non-linearity | 1% |
| Rated output | 1.0 / 2.0 ± 10%mV/V |
| Creep | ±0.25%F.S. / 30min. |
| Zero balance | ±2.0% F.S. |
| Input resistance | 350 ± 5 / 800~1100 Ω |
| output resistance | 350 ± 3/ 800~1100Ω |
| Insulation resistance | ≥5000MΩ / 100VDC |
| Temp.effect on span | ±0.25%F.S. / 10℃ |
| Temp.effect on zero | ±0.25%F.S. / 10℃ |
| Compensated temp range | -10～60℃ / -20～120℃ |
| Use temp range | -20～80℃ / -40～160℃ |
| Excitasion voltage | 5～10V |
| Safe overload | 120%F.S. |
| Ultimate overload | 150%F.S. |
| Defend grade | IP66 |
